RAM-6021 SECURE INDUSTRIAL ROUTER

• LAN-to-LAN or LAN-to-WAN connectivity
• Built in security and routing protects against unwanted intrusion
  • IPsec and SSL VPN tunnels
  • Stateful firewall
  • Port forwarding
  • Packet filtering
  • Access control list (ACL)
• Flexible all-in-one platform reduces system complexity
  • NAT support for one-to-one or one-to-many translations
  • DHCP server and DHCP relay
  • Event engine to trigger I/O or send email alerts
  • SNMP v1, v2, v3
  • Dynamic DNS
  • Modbus TCP/ASCII/RTU
  • DNP3 – slave
  • Syslog
  • Built-in traffic capture for enhanced troubleshooting
  • RAMQTT client for IIoT cloud connectivity

Ethernet Interface (10/100 Auto-Sensing)

• Five (5) RJ-45 type connectors

Mechanical

• Dimensions: 4.7” x 3.77” x 2.0” (120 x 96 x 51 mm)
• Weight: 1.2 lbs. (544 g)

Redundant Power Input

• 4-pin screw terminal
• Side mounted 2.5mm barrel connector
• 8-30 VDC (12 VDC nominal)

Environmental

• Operating temperature: -40° to +70°C
• Humidity: 5 to 95% non-condensing
• Shock: IEC60068-2-27
• Vibration: IEC60068-2-6

Certifications

• Product Safety
  • Hazardous Locations: Class I, Div. 2, Groups A, B, C, D, ISA 12.12.01
